Associated RC10 - Turnbuckles Assembly (Bag F)

12
:: :: Rear Rear SuspensionSuspension Build Build - Bag E - Bag E - Step 3- Step 3
:: :: Turnbuckles Build Turnbuckles Build - Bag F - Bag F - Step 1- Step 1
:: :: Turnbuckles Build Turnbuckles Build - Bag F - Bag F - Step 2- Step 2
Steering Rack Turnbuckle
0.49” (12.44mm)
Dogbone
spring
RC10 tie
rod set
(1”)
RC10 rear
outer
hinge
pins
x2x2
x2x2
6299
E-clip
(small)
6279
Ball cups
(white)
Dogbone
spacer
Dogbone
1
2
x2x2
6279
Ball cups
(white)
RC10 tie
rod set
(1.25”)
Rear Camber Turnbuckle
0.56” (14.20mm)
Use a pair of pliers or
wire cutters to carefully
hold the turnbuckle while
threading on ball cups.
Use a pair of pliers or
wire cutters to carefully
hold the turnbuckle while
threading on ball cups.
!
!
Build left and right sides!Build left and right sides!
Build left and right sides!
