Associated RC10 - Shock Absorber Assembly (Bag G)

13
:: :: Turnbuckles Build Turnbuckles Build - Bag F - Bag F - Step 3- Step 3
:: :: Turnbuckles Build Turnbuckles Build - Bag F - Bag F - Step 4- Step 4
:: :: Shocks Build Shocks Build - Bag G - Bag G - Step 1- Step 1
Piston
2
Remove
spurs
Piston number here
Use #2 = front shocks
Use #2 = rear shocks
x2x2
6279
Ball cups
(white)
RC10 tie
rod set
(1.65”)
Steering Turnbuckle
1.09” (27.70mm)
6299
E-clip
(small)
Shock shaft,
front (0.56)
Shock shaft,
rear (1.32)
Shock
pistons
(1, 2, 3)
6299
E-clip
(small)
TIP: Use marker
to mark the piston
numbers for easy
identification!
!
Front Camber Turnbuckle
0.53” (13.5mm)
RC10 tie
rod set
(1.25”)
x2x2
6279
Ball cups
(white)
Use a pair of pliers or
wire cutters to carefully
hold the turnbuckle while
threading on ball cups.
Use a pair of pliers or
wire cutters to carefully
hold the turnbuckle while
threading on ball cups.
!
!
Build left and right sides!
Build left and right sides!
Build two front and two rear!
