Associated RC10 - Hardware - 1:1 Scale View

3
:: Hardware - 1:1 Scale View:: Hardware - 1:1 Scale View
Notes:
0-80x3/16”
4-40x3/16”
4-40x1/4”
4-40x3/8”
3x6mm (31531)
Button Head (bhcs)
4-40x3/8”
4-40x1/2”
8-32x1/4” (6316)
8-32x1/2” (6316)
8-32x7/8” (6316)
Flat Head (fhcs)
4-40x1/4”
4-40x5/16”
4-40x3/8”
4-40x1/2”
4-40x5/8” (6926)
4-40x3/4”
4-40x1”
Cap Head (shcs)
Bushings
1/4 x 3/8 x 1/8 Flanged
3/16 x 5/16 x 1/8 Flanged
3/16 x 5/16 x 1/4 Flanged
1/8 Diff Balls
Diff Balls
4-40 Small Pattern
Plain Nut
4-40 Steel Locknut
4-40 Nuts
5-40 Diff Locknut
8-32 Nylon Nut, White
8-32 Steel Locknut
Nuts (lock/plain)
4-40x1/8”
4-40x5/16”
Set Screws
E-clip 1/8” (6299)
Bowed E-Clip
Clips
Dogbone spacer
.030 Nylon Spacer (4187)
#4 Washer
1/4” Axle Shim
Diff Thrust Washers
5mm x 9.5mm 0.17mm
#8 Aluminum Thick
Washer
Shims and Washers
