:: Table of Contents:: Table of Contents
:: Notes:: Notes
This symbols indicates a
special note or instruction
in the manual.
There is a 1:1 hardware foldout page in the
front of the manual. To check the size of a part,
line up your hardare with the correct drawing
until you find the exact size.
1................... Cover
2................... Introduction
3....................1:1 Hardware “Fold Out”
4................... Table of Contents
5....................Nose Plate / Steering Build
(Bag A)
5 - 6............. Front Suspension Build
(Bag B)
7 - 10...........Transmission Build
(Bag C)
10 - 11.........Rear Bulkhead Build
(Bag D)
11 - 12.........Rear Suspension Build
(Bag E)
12 - 13........ Turnbuckles Build
(Bag F)
13 - 15........ Shocks Build
(Bag G)
16 ................Chassis Build
(Bag H)
16 - 18........ Electronics Build
(Bag I)
18 - 20....... Wheels, Tires and Body Install
(Bag J)
21................. No tes
22................ Back Cover
!
