Associated RC10 - Nose Plate and Steering Assembly (Bag A); Front Suspension Assembly (Bag B)

5
8/23
:: :: Nose Plate / Nose Plate / Steering Build Steering Build - Bag A - Bag A - - Step 2Step 2
:: :: Front Suspension Front Suspension BuildBuild - Bag B - Bag B -- Step 1Step 1
:: Nose Plate / Steering Build - Bag A - Step 1:: Nose Plate / Steering Build - Bag A - Step 1
6316
8-32 x 7/8
steel
FHCS
6316
8-32 x 1/2
steel
FHCS
6311
RC10 front
nose plate,
Silver
6316
8-32 x 1/4
steel
FHCS
RC10 body
mounts,
Clear
6311
RC10
chassis,
Silver
#8 aluminum
washer (thick)
x2x2
x2x2
#8 aluminum
washer (thick)
8-32 nut,
steel
RC10
steering
assembly,
Clear
RC10 steering
assembly,
Clear
4-40 nut
x2x2
x2x2
Ballstud
.20 (silver)
Ballstud
.20 (silver)
RC10 front
caster blocks,
Clear,
30 degrees
(Left & Right)
x4x4
LEFT
LEFT
Tighten 8-32 nuts
until snug &
bellcrank
rotates freely!
!
LEFT
6299
E-clip
(small)
RC10 steering
blocks,
Clear
(Left & Right)
Ballstud
.20 (silver)
RC10 front
stub axles
Press stub axles
into steering blocks.
Use a hard surface
to push down on!
!
Build left and right sides! Build left and right sides!
