Introduction to the Series 40 Conveyor
Material fl ow
Conveyor orientation is
determined by standing at the
tail end of the conveyor looking
toward the direction of travel.
The conveyor is in the operating
position when it has been
elevated to a working position.
References to the right hand
and/or left hand side will be as
shown below.
Head pulley
Tail pulley
