ASTEC 40 Series User Manual

IB-2003
S
eries 40 Trans
fl
ite -
S
tationary
C
onveyor
16
Introduction to the Series 40 Conveyor
Troughing Idlers
Troughing idlers form the belt
in a curved shape to carry
material .
They are CEMA Class B or
C type sealed for life ball
bearings, 3 roll 35 degree, 5”
diameter steel on 4’ centers.
Optional impact idlers cushion
impact and protect the belt
from damage in high capacity
applications.
Return Idlers
The return idlers support the
belt on its return trip to the
loading point.
The return idlers are CEMA
Class B or C type, sealed for
life ball bearings, one single
steel roll.
Rubber disc return idlers are
optional.
