2 Machine description
This chapter provides a comprehensive overview of the structure and function of
the machine. Read it as far as possible at the machine. This will allow you to
become familiar with the machine.
2.1 Technical specifications
Pressing force 500 kg
Plunger stroke 45 mm
Height with lever 580 mm
Width 170 mm
Depth 238 mm
Empty weight 9 kg
2.2 Maintenance and care
In the case of continuous use, the movable machine parts are to be thoroughly cleaned
once a week with a brush and cleaning cloth to remove dust, lint and fabric residue.
The plunger projecting beyond the plunger guide is to be lubricated.
To avoid malfunctions, the original tool must be cleaned once a week (brush and
cleaning cloth).
Do not use hard objects such as scissors, screwdrivers, abrasive paper.
