ENGLISH

Nº CODE DESCRIPTION 21626 35666 Q Nº CODE DESCRIPTION 21626 35666 Q

1 21626R0002 Face plate ring X 1 14 00346R0012 Plastic washer X X 1

2 35666R0001 Rustproof decorative ring X 1 15 00346R0011 Cable gland gasket X X 1

3 00373 Clear lens X X 1 16 21626R0006 Cable gland connector X X 1

4 00346R0004 Silicon gasket X X 1 17 21626R0203 Flat gasket X X 1

5 00371 Halogen lamp 12 V 100 W X X 1 18 21626R0202 Cable gland nut PG-9 X X 1

6 7012102000 Nut DIN 934 A2 M-2 X X 2 19 00346R0005 Cable gland nut PG-9 X X 1

7 00360R0002 Lamp holder X X 1 20 00346R0009 Cable gland washer X X 1

8 21626R0004 Reflector X X 1 21 00346R0006 Cable gland gasket PG-9 X X 1

9 7011429095 Screw DIN 7981 2,9x9,5 X X 3 22 00346R0015 Conduit connector X X 1

10 7013202010 Screw DIN 7985 A2 M-2x10 X X 2 23 7011448025 Screw DIN 7981 A2 4,8x25 X X 4

11 21626R0001 Rear protection screen X X 1 24 21626R0003 Mounting bracket X X 1

12 21626R0005 Electrical cable 2,5m 2x1,5 X X 1 25 00346R0008 Screw anchor S-6 X X 4

13 21626R0007 Cable gland plug X X 1

FRANÇAIS

Nº. CODE DESCRIPTION 21626 35666 Q Nº CODE DESCRIPTION 21626 35666 Q

1 21626R0002 Anneau enjoliveur X 1 14 00346R0012 Rondelle de plastique X X 1

2 35666R0001 Anneau enjoliveur X 1 15 00346R0011 Joint presse-étoupe X X 1

3 00373 Lente transparente X X 1 16 21626R0006 Corps presse-étoupe X X 1

4 00346R0004 Joint lente projecteur X X 1 17 21626R0203 Joint plat X X 1

5 00371 Lampe hallogène 12 V 100 W X X 1 18 21626R0202 Écrou presse-étoupe M16 X X 1

6 7012102000 Écrou DIN 934 A2 M-2 X X 2 19 00346R0005 Écrou presse-étoupe PG-9 X X 1

7 00360R0002 Porte-lampe X X 1 20 00346R0009 Rondelle presse-étoupe X X 1

8 21626R0004 Réflecteur X X 1 21 00346R0006 Joint presse-étoupe PG-9 X X 1

9 7011429095 Vis DIN 7981 2,9x9,5 X X 3 22 00346R0015 Corps passe-murs X X 1

10 7013202010 Vis DIN 7985 A2 M-2x10 X X 2 23 7011448025 Vis DIN 7981 A2 4,8x25 X X 4

11 21626R0001

Écran posterérieur du projecteur

X X 1 24 21626R0003 Croisillon de support X X 1

12 21626R0005 Câble 2x1,5 de 2,5m X X 1 25 00346R0008 Cheville S-6 X X 4

13 21626R0007 Bouchon presse-étoupe X X 1
