9.4. INFORMATION ON THE HEATER INPUT TYPE REGISTERS (READ)
Name
Address
Initial
value
Information
Operation Mode
0x00
0
Reports the operating mode of the heater. It is a
reflection of the operating orders in the Holding Register
0x21.
bit 0 0: No alarms.
1: There is an alarm present.
bit 1 1= °C
0= °F
bit 8 Manual On / Off
1: Heater on
0: Heater off
Alarms
0x01
0
Displays the alarms information in real time. Each bit has
a meaning associated with a type of alarm.
Bit
Alarm
0
Not used.
1
Overheating alarm (Tin or Tout > 55°C).
2
3
Flow needed and not present.
4
5
6
7
8
9
10
11
12
13
14
Freezing risk (Tin < 5°C).
15
Digital Inputs
Status
0x02
0
Indicates the status of the digital inputs:
Bit 0 0: No water flow.
1: Water flow detected.
Bit 1 0: Heating element #1# off.
1: Heating element #1# on
Bit 2 0: Heating element #2# off
1: Heating element #2# on
Bit 3 0: Heating element #3# off
1: Heating element #3# on
Inlet water
temperature
0x07
Shown in degrees both Celsius and Fahrenheit.
Outlet water
temperature
0x08
Shown in degrees both Celsius and Fahrenheit.
