Astralpool PRO-ELYO INVERBOOST 48707M - Maintenance Instructions

- 65 -
12
Front panel
133050008
41
Piping
113080060
13
Front grill
108140011
42
Piping
113060094
14
Water outlet temp. sensor TH5
117110052
43
Piping
113050108
15
Water inlet temp. sensor clip
108010025
44
Distributor tube
113040093
16
Base tray
108140051
45
Sensor casing pipe
113190001
17
Electric box cover
108030059
46
Clip
113190001
18
Water flow switch
116000001
47
Blue rubber ring
133020006
19
Compressor
101000142
48
Water connection cover
102040501
20
Titanium heat exchanger
102040501
49
Heating pipe temp. sensor
117110050
21
PCB
117100014
50
Pressure gauge
106000001
22
Water inlet temp. sensor clip
108010025
51
Red rubber ring
133020007
23
Water inlet temp. sensor
117110053
52
Water connection cover
102040501
24
Electric box
108030095
53
Piping
113030091
25
Drainage plug
102040501
54
4 way valve
121000001
26
Wiring box
108160024
55
Exhaust pipe
113010182
27
Right panel
133050055
56
Exhaust pipe temp. sensor
117110051
28
5-seat terminal
115000004
57
Ambient temp. sensor clip
117110049
29
Clip
136010004
58
Ambient temp. sensor
133020010
9.3 Maintenance
(1) You should check the water supply system regularly to avoid the air entering the system and occurrence of low
water flow, because it would reduce the performance and reliability of HP unit.
(2) Clean your pools and filtration system regularly to avoid the damage of the unit as a result of the dirty of clogged
filter.
(3) You should discharge the water from bottom of water pump if HP unit will stop running for a long time
(especially during the winter season).
(4) In another way, you should check the unit is water fully before the unit start to run again.
(5) After the unit is conditioned for the winter season, he is preconized to cover the heat pump with special winter
heat pump.
(6) When the unit is running, there is all the time a little water discharge under the unit.
