To Next PageTo Next PageWhat to do if my Astralpool Heat Pump has a gas return sensor failure?
If your Astralpool Heat Pump shows a gas return sensor failure, it could be due to the sensor being in an open or short circuit, or the wiring of the sensor being loose. Check or change the sensor and re-fix the wiring of the sensors.
What to do if my Astralpool Heat Pump shows a water flow failure TS1?
If your Astralpool Heat Pump displays a water flow failure TS1, it could be due to a damaged water flow switch or insufficient water flow. Try replacing the water flow switch or checking the filtration pump and waterway system to ensure adequate water flow.
Why is my Astralpool PRO ELYO INVERBOOST NN Heat Pump showing compressor current protection?
Compressor current protection in your Astralpool Heat Pump can occur due to several reasons: the compressor current being too large instantaneously, incorrect connection for compressor phase sequence, compressor accumulations of liquid and oil, a damaged compressor or driver board, abnormal water flow, or power fluctuations. To resolve this, check the compressor, compressor phase, power range, phase sequence connection, the waterway system and filtration pump, and mains power input.
What to do if my Astralpool PRO ELYO INVERBOOST NN has The inter-chip communication failure on the main control board?
If your Astralpool Heat Pump experiences an inter-chip communication failure on the main control board, it indicates a main board failure. Turn off the electricity supply and restart it, or change the main board.
What to do if my Astralpool Heat Pump has an ambient temperature sensor failure T5?
If your Astralpool Heat Pump shows an ambient temperature sensor failure T5, it could be due to the sensor being in an open or short circuit, or the wiring of the sensor being loose. Check or change the sensor and re-fix the wiring of the sensors.
What does compressor phase failure mean for my Astralpool PRO ELYO INVERBOOST NN Heat Pump?
Compressor phase failure in your Astralpool Heat Pump means that the compressors U, V, W are connected to one phase or two phases. Check the actual wiring according to the circuit diagram.
What to do if my Astralpool Heat Pump shows IPM module temperature too high protection?
If your Astralpool Heat Pump displays an IPM module temperature too high protection error, it could be due to an output exception of the IPM module thermal circuit, an abnormal or damaged motor, or a broken fan blade. Try changing the driver board, checking if the fan motor speed is too low or fan motor is damaged, or changing the fan blade.
What causes PFC module protection in Astralpool Heat Pump?
PFC module protection in your Astralpool Heat Pump can be triggered by an output exception of the PFC module, an abnormal or damaged motor, a broken fan blade, or abnormal input power. To solve this, change the driver board, check if the motor speed is too low or fan motor is damaged, change the fan blade, or check the input voltage.
What to do if my Astralpool PRO ELYO INVERBOOST NN Heat Pump has four-way valve reversal failure?
If your Astralpool Heat Pump experiences a four-way valve reversal failure, it may be due to the valve failing to reverse or a lack of refrigerant. Switch to cooling mode to check if the 4-way valve has been reversed correctly, change the 4-way valve, or fill with gas.
How to resolve communication failure between Main control board and Driving board in Astralpool PRO ELYO INVERBOOST NN Heat Pump?
A communication failure between the Main control board and Driving board in your Astralpool Heat Pump is likely caused by a poor connection of the communication wire or a damaged wire. Check the wire connection and replace the wire if necessary.
Wiring diagram for inverter pool heat pumps (Models 71676/71677/71678/71679/71680).
Wiring diagram for inverter pool heat pumps (Model 71681).
Wiring diagram for inverter pool heat pumps (Models 71682/71683).
Wiring diagram for inverter pool heat pumps (Model 68822 (R410A)).
Wiring diagram for inverter pool heat pumps (Models 68821/68823 (R410A)).
Guidelines and requirements for the electrical connection of the heat pump.
Describes the logic and conditions for heating operation modes.
Lists error codes, their reasons, and solutions for LED wire controller displays.
Troubleshooting guide for malfunctions not indicated by error codes on the controller.
Wiring diagram for inverter pool heat pumps (Models 71676/71677/71678/71679/71680).
Wiring diagram for inverter pool heat pumps (Model 71681).
Wiring diagram for inverter pool heat pumps (Models 71682/71683).
Wiring diagram for inverter pool heat pumps (Model 68822 (R410A)).
Wiring diagram for inverter pool heat pumps (Models 68821/68823 (R410A)).
Guidelines and requirements for the electrical connection of the heat pump.
Describes the logic and conditions for heating operation modes.
Lists error codes, their reasons, and solutions for LED wire controller displays.
Troubleshooting guide for malfunctions not indicated by error codes on the controller.
General| Category | Heat Pump |
|---|---|
| Max Water Temperature | 40°C |
| Refrigerant | R32 |
| IP Rating | IPX4 |
| Ambient Temperature Range | 43°C |
