PARTS BREAKDOWN
DIMMING FUNCTION
BATTERY TREATMENT/CHARGING
WARNING
Both main lights have an adjustable dimming function.
Press and hold the power button or the dual power
button to initiate the light’s dimming. Release the button
when the desired light level is reached. The light will
blink once when the lower or upper limit is reached.
Lower light levels will increase battery life.
• Charge the battery for at least 8 hours before first use
• Green indicator on light flashing: charging
• All green indicators lighting up on light means
charging complete
• Do not leave battery in full discharged condition
• Recharge the work light at least once in every 30 days
• Wear safety goggles (User and bystander)
• Avoid looking directly into the beam
• Do not use the light near open flames
• Do not cover the lens during the operating to
prevent against overheating
• Do not contaminate the lens with organic solvents
• Take care to position the light and stand in a careful
manner, to ensure the light is properly
supported by the stand
Specification:
5V 2A
3.7V 4400mAh Li-ion
~ 4hrs
~ 6.5hrs
~ 3.25 - 8hrs
~ 8hrs
100 - 1000 lumen
150 lumen
5500 - 6500K
Charging voltage/Current:
Battery specification:
Charging time via type-C:
Charging time via charging pad:
Operation time for main light:
Operation time for top light:
Main lights output:
Brightness for top light:
Color temperature:
Product Type:Model:
52SL
500X2 LUMEN WIRELESSLY RECHARGEABLE
FOLDING DOUBLE-SIDED LED SLIM LIGHT
Wireless Charging Base
1
2
3
52SL-WCP Dual Wireless
Charging Pad
Available Separately
4
Parts List
Qty
1
2
3
4
52SL-01
52SL-02
52SL-03
52SL-04
Wall Adapter
USB-C cable
Hook
Sticker Label for Magnet
Index Part No. Description
1
1
1
1
