Astro Pneumatic 1442 - Parts Breakdown; Parts List and Identification

13" NUT/THREAD SETTING HAND RIVETER KIT WITH
3PC METRIC AND 3PC SAE MANDREL/NOSEPIECE SETS
AND RIVET NUT ASSORTMENT
8
1442-A01
1442-A02
1442-A03
1442-A04
1442-A05
1442-A06
1442-A07
1442-A08
1442-A09
1442-16
1442-06
1442-04
1442-03
1442-A14
1442-A15
1442-07
1442-09
1442-15
1442-13
1442-A20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
M8 Nosepiece
M8 Mandrel 8mmx1.25
Sleeve
Adjusting Nut
Spacer
Hexagonal Sleeve
Riveting Bar
Spacer
Spring
Main Body
Screw
Bushing
Locknut
Opening Spring Pins
Pulling Bar
Metal Washer
Connecting Bar
Main Shaft Drive
Knob
Spacer
1
1
1
1
1
1
1
2
1
1
4
4
4
1
1
8
2
1
1
5
Index Part No. Description Qty
1442-11
1442-08
1442-10
1442-02
1442-01
1442-A26
1442-A27
1442-A28
1442-A29
1442-A30
1442-A31
1442-A32
1442-A33
1442-A34
1442-A35
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
Screw
Connecting Bar
Bushing
Handle
Grip
Mandrel 5/16-18
5/16-18 Nosepiece
M6 Mandrel 6mmx1.0
M6 Nosepiece
M5 Mandrel 5mmx0.8
M5 Nosepiece
Mandrel 1/4-20
1/4-20 Nosepiece
Mandrel 10-24
10-24 Nosepiece
1
4
2
2
2
1
1
1
1
1
1
1
1
1
1
Index Part No. Description Qty
Parts List
1442
Page 4
MODEL: PRODUCT TYPE:
PARTS BREAKDOWN
