ll. SAFETY GUIDE:
1. Wear adequate protective gear including ANSI
approved goggles and
thick work gloves.
2. Only use the nut riveting adapter with driving tool that
matches with requirements specified on Product
Technical Data.
3. Switch off the driving tool before installing or
uninstalling the nut riveting adapter.
I. Product Technical Data:
Dimensions:
Weight:
Hex Shank Size:
Riveting Capability:
Rivet Type:
Stroke Limit:
Working Torque:
Recommended RPM:
Requirements of Driving Tools:
Sizing Chart:
ADN14
MODEL: PRODUCT TYPE:
Page 2
8.5" x 5.5" x 2.4"
2.4 lbs
1/4"
Rivet Nut
Maximum 0.7 inch
Refer to section III. Operation Guide
Low speed (<240 RPM)
Requirements of cordless driving tool:
• adjustable torque setting
• chuck capacity of 6.35 mm (1/4") shank
• min 12V and maximum torque > 190 in/lbs for aluminum and rivet nuts
• min 14.4V and maximum torque > 250 in/lbs for stainless steel rivet nuts
• clutch provides a felt and/or audible indication of reaching max setting
Requirements of elctric or pneumatic driving tool:
• adjustable torque setting
• chuck capacity of 6.35 mm (1/4") shank
• with maximum torque > 190 in/lbs for aluminum and steel rivet nuts
• with maximum torque > 250 in/lbs for stainless steel rivet nuts
• clutch provides a felt and/or audible indication of reaching max setting
Rivet Nut Size
Nut
Material
SAE
8-32
SAE
10-24
SAE
10-32
SAE
1/4-20
M3 M4 M5 M6
Aluminum
Steel/Copper
Stainless Steel
RIVET NUT DRILL ADAPTER KIT
Rivet Nut
M3
M4
M5
M6
8-32
10-32
10-24
1/4-20
Rivet Nut Diameter
4.9mm OD
5.9mm OD
6.87mm OD
8.80mm OD
5.9mm OD
6.87mm OD
6.87mm OD
9.76mm OD
Drill Hole Size
5mm (13/64")
6mm (7/32")
7mm (9/32")
9mm (3/8")
6mm (7/32")
7mm (9/32")
7mm (9/32")
10mm (13/32")
Grip Range
26 – 16ga
26 – 16ga
26 – 16ga
26 – 13ga
26 – 16ga
26 – 16ga
26 – 16ga
26 – 13ga
4. The objects to be riveted MUST BE SECURELY FIXED
BEFORE riveting in order to avoid possible injury.
Unsecured objects may rotate with the driving tool if not
secured.
5. The driving tool MUST be stopped if user releases the
adapter’s body during riveting.
6. During disassembly for mandrel changing or
Maintenance, take care as there are pre-loaded springs
within the tool.
