ASTRO MIXAMP M80 - MixAmp M80 LED Behavior; LED Behavior: Master Volume; LED Behavior: Game; Voice Balance; LED Behavior: EQ Settings

ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
MIXAMP
TM
M80 LED BEHAVIOR
LED Behavior:
Master Volume
LED Array will fill up according to Volume. One LED will light up according to
Game / Voice Balance.
LED Behavior:
Game / Voice Balance
Several LEDS will light up on the left,
middle and right indicating the selected EQ mode.
LED Behavior:
EQSettings
