MixAMP
TM
M80 USER INTERFACE
ASTRO GAMING
CONFIDENTIAL 2013
EYES ONLY
010185
Turn wheel to the right to
increase volume, turn to
the left to decrease volume.
Press to toggle between 3 EQ Modes.
Press to mute microphone.
Red: Muted
Press for more
Game Audio.
Press for more
Voice Audio.
Game/Voice Balance: The M80’s integrated game and voice mixing functions are located on either side of the bottom
of the device. To adjust, press the button for the desired audio function to incrementally increase. Holding down
“Game” will cause the mixing function to increase the volume of game sounds, while quieting the voice, whereas
pressing “Voice” will cause the mixer to decrease the volume of game sounds, while amplifying voice.
Master Volume: The Master Volume wheel located between the two buttons adjusts overall volume control. Use the
Master Volume in conjunction with Game/Voice Balance for total audio domination.
Mute Microphone: To activate the microphone's mute feature, simply press the button on the front volume wheel.
.
Equalizer (EQ) Modes: EQ modes are controlled by a button below the LED light indicators. The M80 comes equipped
with three separate EQ modes for better listening:
1. Pro: Boosted high frequencies for competitive gameplay (Left)
2. Core: Balanced for single player gaming (Middle)
3. Media: Enhanced bass, for movies and music (Right)
