Asus 4G-AX56 User Manual

75
4.6.4 Network Services Filter
The Network Services Filter blocks LAN to WAN packet exchanges
and restricts network clients from accessing specific web services
such as Telnet or FTP.
To set up a Network Service filter:
1. From the navigation panel, go to Advanced Settings >
Firewall > Network Service Filter tab.
2. On the Enable Network Services Filter field, select Ye s.
3. Select the Filter table type. Black List blocks the specified
network services. White List limits access to only the specified
network services.
4. Specify the day and time when the filters will be active.
5. To specify a Network Service to filter, enter the Source IP,
Destination IP, Port Range, and Protocol. Click the button.
6. Click Apply.
4.6.5 IPv6 Firewall
By default, your ASUS wireless router blocks all unsolicited
incoming traffic. The IPv6 Firewall function allows incoming traffic
coming from specified services to go through your network.

Asus 4G-AX56 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, WAN
Housing material	Plastic
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1201 Mbit/s
WLAN data transfer rate (first band)	54 Mbit/s
WLAN data transfer rate (second band)	11 Mbit/s
Antennas quantity	4
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g
Ethernet LAN interface type	Gigabit Ethernet
Flash memory	128 MB
Internal memory	512 MB
Power source type	DC
4G standard	LTE-FDD
3G standards	UMTS
SIM card type	NanoSIM
Mobile network generation	4G
Ethernet LAN (RJ-45) ports	5
Cables included	LAN (RJ-45)
NAT functionality	PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay
Security algorithms	IPSec, SIPS

Weight and Dimensions

Weight	753 g
