Asus A68HM-K User Manual

2-14
Chapter 2: Getting started
2.9 Tools menu
The Tools menu items allow you to congure options for special functions. Select an item
then press <Enter> to display the submenu.
2.10 Exit menu
The Exit menu items allow you to load the optimal default values for the BIOS items, and
save or discard your changes to the BIOS items. You can access the EZ Mode from the Exit
menu.
E9808_A68HM Series_Manual.indb 14 2014/10/16 10:09:11

Asus A68HM-K Specifications

General

Form Factor	Micro ATX
Chipset	AMD A68H
CPU Socket	FM2+
Memory Slots	2
Memory Type	DDR3
Max Memory	32GB
Memory Standard	DDR3 2400(O.C.)/2133/1866/1600/1333 MHz
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4 x SATA 6Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 10, JBOD
USB 3.0 Ports	2 x USB 3.0 (2 at back panel, blue)
LAN	Realtek 8111GR, 1 x Gigabit LAN Controller
Onboard Video	Integrated AMD Radeon R Series Graphics in A-series APU
