Asus A6J - LAN PORT; MDC

5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
LAN PORT
FOR EMI
12G161200120
MDC
Close R4004
to CON4004
Must change to
13-N7510M270
LAN SWAPED-1013
Custom
32 63Tuesday, November 22, 2005
ASUSTeK COMPUTER INC
RJ11+45,MDC
2.0
A6J
Marco Chen
<Variant Name>
Size Project Name
Rev
Date: Sheet of
Title :
Engineer:
GND_LAN
MODEM_TIP_CON
LTRLM3
LTRLM2
LTRLP1
MODEM_TIP
MODEM_RINGMODEM_RING_CON
LTRLM0
LTRLM1
LTRLP2
LTRLP3
LTRLP0
L_TRLM1
L_CMT3
L_CMT2
L_TRLM0
L_TRLP1
L_CMT0
L_CMT1
L_TRLP0
L_TRLP3
L_TRLM3
L_TRLP2
L_TRLM2
L_TRLM0
L_TRLP2
L_TRLM2
L_TRLM1
L_TRLP3
L_TRLM3
L_TRLP0
L_TRLP1 LTRLP1
LTRLM1
LTRLM3
LTRLP3
LTRLM2
LTRLP2
LTRLM0
LTRLP0
L_CMT2
L_CMT1
L_CMT3
L_CMT0
GND
GND
GND
GNDGND
+3V
GND
GND GND
GND
GNDGND
GNDGNDGND
C3206
0.01UF/50V
c0402
12
C3208
0.01UF/50V
c0402
12
RN3202B 75Ohm
3 4
C3203
1000PF/3KV
12
C3201
0.01UF/50V
c0402
12
CON3201
WTOB_CON_2P
3
4
1
2
SIDE1
SIDE2
1
2
C3210
22PF/50V
@
c0402
12
C3207
0.01UF/50V
c0402
12
CON3203 BTOB_CON_12P
1 2
3 4
5 6
7 8
9 10
11 12
1314 1920 1516 1718
12
34
56
78
910
11 12
GND1GND2
NP_NC1NP_NC2
GND3GND4 GND5GND6
MCT1
MCT2
MCT3
MCT4
MX1+
MX1-
MX2+
MX2-
MX3+
MX3-
MX4+
MX4-
TCT1
TD1+
TD1-
TD2+
TD2-
TD3+
TD3-
TD4+
TD4-
TCT2
TCT3
TCT4
U3201
1GB
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
RN3201A
0Ohm
1 2
R3202 0Ohm
1 2
CON3202
MODULAR_JACK_12P
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
2
3
4
5
6
7
8
9
10
11
12
NP_NC1
NP_NC2
P_GND1
P_GND2
SIDE1
SIDE2
RN3201C
0Ohm
5 6
RN3201B
0Ohm
3 4
RN3202D 75Ohm
7 8
C3205
1000PF/2KV
12
RN3203B
0Ohm
3 4
L3201
1KOhm/100Mhz
21
RN3202C 75Ohm
5 6
RN3201D
0Ohm
7 8
RN3203C
0Ohm
5 6
H3202
L4E_1A
RN3203D
0Ohm
7 8
C3209
0.1UF
c0402
12
RN3203A
0Ohm
1 2
RN3202A 75Ohm
1 2
C3202
1000PF/3KV
12
H3201
L4E_1A
L3202
1KOhm/100Mhz
21
ACZ_SDIN123
ACZ_SYNC_MDC23
ACZ_SDOUT_MDC23
ACZ_BCLK_MDC 23ACZ_RST#_MDC23
L_TRDP031
L_TRDM131
L_TRDP131
L_TRDM031
L_TRDP231
L_TRDM331
L_TRDM231
L_TRDP331
