14. Page40: Remove L4003, L4005, L4007, L4008 for EMI requirement.
15. Page43: Mount R4301*100K ohm to avoid PWR_SW# is floating.
16. Page43: Mount R4327*10K ohm to fix DJ_LED light soon issue when power on.
Custom
49 63Tuesday, November 22, 2005
<OrgName>
History(2)
2.0
A6J
Marco Chen
<Variant Name>
Size Project Name
Rev
Date: Sheet
of
Title :
Engineer:
