1.2.4 Layout contents
1.3 Central Processing Unit (CPU)
ThismotherboardcomeswithasurfacemountLGA1151socketdesignedforthe6th
GenerationIntel
®
Core™i7/Core™i5/Core™i3,Pentium
®
andCeleron
®
processors.
Connectors/Jumpers/Slots/LED Page
1. ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V)
1-17
2. CPU,chassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN1~2) 1-15
3. Intel
®
LGA1151CPUsocket 1-3
4. DDR4DIMMslots 1-7
5. Intel
®
B150SerialATA6.0Gb/sconnector(7-pinSATA6G_1~6) 1-20
6. M.2Socket3 1-20
7. ClearRTCRAM(2-pinCLRTC) 1-12
8. Systempanelconnector(20-5pinPANEL)
1-19
9. USB3.0connector(20-1pinUSB3_12) 1-16
10. USB2.0connector(10-1pinUSB1112) 1-16
11. Serialportconnector(10-1pinCOM) 1-15
12. Digitalaudioconnector(4-1pinSPDIF_OUT) 1-18
13. Frontpanelaudioconnector(10-1pinAAFP) 1-18
B150-PRO
B150-PRO CPU socket LGA1151
