ASUS B150M-C D3

1-3

1.2.4 Layout contents

1.3 Central Processing Unit (CPU)

ThismotherboardcomeswithasurfacemountLGA1151socketdesignedforthe6th

GenerationIntel

Core™i7/Core™i5/Core™i3,Pentium

andCeleron

processors.

B150M-C D3

B150M-C D3 CPU socket LGA1151

Connectors/Jumpers/Slots/LED Page

1. CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN1/2) 1-17

2. ATXpowerconnectors(24-pinEATXPWR,4-pinATX12V) 1-15

3. LPTconnector(26-1pinLPT) 1-15

4. Intel

LGA1151CPUsocket 1-3

5. DDR3DIMMslots 1-7

6. USB3.0connector(20-1pinUSB3_12) 1-19

7. Intel

B150SerialATA6.0Gb/sconnector(7-pinSATA6G_1~6[gray]) 1-18

8. Speakerconnector(4-pinSPEAKER) 1-17

9. Systempanelconnector(10-1pinF_PANEL) 1-20

10. Chassisintrusionheader(4-1pinCHASSIS) 1-12

11. ClearRTCRAM(2-pinCLRTC) 1-11

12. USB2.0connectors(10-1pinUSB7~10) 1-19

13. Serialportconnectors(10-1pinCOM1,COM2) 1-18

14. TPMconnector(14-1pinTPM) 1-16

15. Frontpanelaudioconnector(10-1pinAAFP) 1-16
