Asus B150M-PLUS - USB 3.0 Connector (20-1 Pin USB3_12)

ASUS B150M-PLUS
1-17
3. USB 3.0 connector (20-1 pin USB3_12)
ThisconnectorallowsyoutoconnectaUSB3.0moduleforadditionalUSB3.0front
orrearpanelports.WithaninstalledUSB3.0module,youcanenjoyallthebenetsof
USB3.0includingfasterdatatransferspeedsofupto5Gbps,fasterchargingtimefor
USB-chargeabledevices,optimizedpowerefciency,andbackwardcompatibilitywith
USB2.0.
TheUSB3.0moduleispurchasedseparately.
B150M-PLUS
B150M-PLUS USB3.0 Front panel connector
USB3_12
USB3+5V
IntA_P1_SSRX-
IntA_P1_SSRX+
GND
IntA_P1_SSTX-
IntA_P1_SSTX+
GND
IntA_P1_D-
IntA_P1_D+
GND
PIN 1
USB3+5V
IntA_P2_SSRX-
IntA_P2_SSRX+
GND
IntA_P2_SSTX-
IntA_P2_SSTX+
GND
IntA_P2_D-
IntA_P2_D+
4. USB 2.0 connector (10-1 pin USB910,1112)
ThisconnectorisforUSB2.0ports.ConnecttheUSBmodulecabletothisconnector,
then install the module to a slot opening at the back of the system chassis. This
USBconnectorcomplieswithUSB2.0specicationsandsupportsupto480Mbps
connection speed.
Neverconnecta1394cabletotheUSBconnector.Doingsowilldamagethemotherboard!
TheUSB2.0moduleispurchasedseparately.
B150M-PLUS
B150M-PLUS USB2.0 connectors
USB+5V USB_P9- USB_P9+ GND NC
USB+5V
USB_P10-
USB_P10+
GND
USB910
PIN 1
USB+5V USB_P11- USB_P11+ GND NC
USB+5V
USB_P12-
USB_P12+
GND
USB1112
PIN 1
