Asus GR701 - Page 5

4
90DC00F0-B0014C
GR701 FIO MODULE WW/CSC｜FIO module
Fully-assembled. (Consists of FIO module*1, FIO panel*1, Flat round head M3 chassis
screws*2)
Disassembly method: Remove the top filter, then unscrew the screws.
FAQ: FIO buttons and ports not working, Case lighting not working
90DC00F0-B0005C
GR701 FRONT PANEL/CSC｜Front panel
Fully-assembled. (Consists of Upward triangular light guide panels*1, Downward triangular
light guide panels*1, Upward light board*1, Downward light board*1, T3*4 self-tapping
screws*2)
Disassembly method: Remove the top filter, FIO module and front side fans, then unscrew the
screws.
FAQ: Case lighting not working
