Asus M2N-VM DH User Manual

1-18 Chapter 1: Product introduction
Side (s): SS - Sin gle -side d DS - Do uble- sided
DIMM support :
A - Supports one module inserted in any slot as Single-channel memory configuration.
B - Supports one pair of modules inserted into either the yellow slots or the black slots as
one pair of Dual-channel memory configuration.
C - Supports 4 modules inserted into both the yellow and black slots as two pairs of
Dual-channel memory configuration.
Visit the ASUS website for the latest DDR2-800/667/533 MHz QVL.
256MB KINGSTON E5116AF-5C-E N/A SS KVR533D2N4/256 •
512MB KINGSTON HYB18T512800AF37 N/A SS KVR533D2N4/512 • • •
1024MB KINGSTON 5YDIID9GCT N/A DS KVR533D2N4/1G • • •
512MB Qimonda HYB18T512800AC37 N/A SS HYS64T64000GU-3.7-A • • •
256MB Qimonda HYB18T512160AF-3.7 N/A SS HYS64T32000HU-3.7-A • • •
512MB Qimonda HYB18T512800AF37 N/A SS HYS64T64000HU-3.7-A • • •
1024MB Qimonda HYB18T512800AF37 N/A DS HYS64T128020HU-3.7-A • •
2048MB Qimonda HYB18T1G800AF-3.7 N/A DS HYS64T256020HU-3.7-A • •
256MB Qimonda HYB18T5121608BF-3.7 N/A SS HYS64T32000HU-3.7-B • •
512MB Qimonda HYB18T512800BF37 N/A SS HYS64T64000HU-3.7-B • • •
1024MB Qimonda HYB18T512800BF37 N/A DS HYS64T128020HU-3.7-B • •
512MB Hynix HY5PS12821F-C4 N/A SS HYMP564U648-C4 • • •
512MB Hynix HY5PS12821F-C4(ECC) N/A SS HYMP564U728-C4 • •
1024MB Hynix HY5PS12821F-C4 N/A DS HYMP512U648-C4 • • •
1024MB Hynix HY5PS12821FP-C4 N/A DS HYMP512U648-C4 • •
512MB Hynix HY5PS12821AFP-C3 N/A SS HYMP564U64AP8-C3 • • •
1024MB Hynix HY5PS12821AFP-C3 N/A DS HYMP512U64AP8-C3 • • •
512MB ELPIDA E5108AB-5C-E N/A SS EBE51UD8ABFA-5C • •
512MB ELPIDA E5108AB-5C-E N/A SS EBE51UD8ABFA-5C-E • • •
256MB Apacer E5116AB-5C-E N/A SS 78.81077.420 • •
256MB KINGMAX E5116AB-5C-E N/A SS KLBB68F-36EP4 • • •
512MB KINGMAX E5108AE-5C-E N/A SS KLBC28F-A8EB4 • •
1024MB KINGMAX E5108AE-5C-E N/A DS KLBD48F-A8EB4 •
512MB KINGMAX KKEA88E4AAK-37 N/A SS KLBC28F-A8KE4 • •
1024MB KINGMAX 5MB22D9DCN N/A DS KLBD48F-A8ME4 • •
DDR2-533 MHz capability
Size Vendor Model Brand Side(s) Component A B C
DIMM support

Asus M2N-VM DH Specifications

General

ECC	No
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
Maximum number of SMP processors	1
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of SATA connectors	5
I/O ports	1x WiFi-AP Solo antenna
Special features	ASUS WiFi-AP Solo Asus DH Remote ASUS MP3-In ASUS C.P.R. Q-Fan2 MyLogo2 EZ Flash 2
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE, Chassis Intrusion
Controller interface type	JMicron JMB363
Controller 2nd interface type	NVIDIA nForce 430
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	ADI AD1988
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Bundled software	Drivers ASUS DH Remote Application ASUS WiFi-AP Solo Wizard Nvidia MediaShield RAID ASUS PC Probe 2 AMD Cool ' n' Quiet Utility ASUS LiveUpdate Utility Anti-Virus software (OEM)
Graphics card	GeForce 6100
Networking features	Gigabit Ethernet, Wireless LAN
BIOS memory size	32 Mbit
RAID levels	0, 1, 0+1, 5, JBOD

Weight and Dimensions

Width	245 mm
