IRQ assignments for this motherboard
A B C D E F G H
PCIe x16_1 - - - - shared - - -
PCIe x16_2 - - - - shared - - -
PCIe x1_1 - - - - - - shared -
PCIe x1_2 - - - - - shared - -
PCI 1 - - - - shared - - -
PCI 2 - - - - - shared - -
Realtek 8111F (LAN) - - - - shared - - -
ASMedia USB 3.0
(port 1 & port 2)
- - - - shared - - -
ASMedia USB 3.0
(port 3 & port 4)
- - - - - - shared -
On Chip SATA - - - shared - - - -
On Chip USB 1 - - shared - - - - -
On Chip USB 2 - - shared - - - - -
On Chip USB 3 - - shared - - - - -
HD Audio shared - - - - - - -
• In single VGA card mode, use the PCIe 2.0 x16_1 slot (navy blue) for a PCI Express
x16 graphics card to get better performance.
• We recommend that you provide sufcient power when running CrossFireX™ mode.
• Connect a chassis fan to the motherboard connector labeled CHA_FAN1/2/3 when
using multiple graphics cards for better thermal environment.
