ASUS M5A97 PLUS
2-13
Current CPU Speed : xxxxMHz
Displays the current CPU speed.
Target CPU Speed : xxxxMHz
Displays the target CPU speed.
Current Memory Frequency : xxxxMHz
Displays the current memory frequency.
Current NB Frequency : xxxxMHz
Displays the current NB frequency.
Current HT Link Speed : xxxxMHz
Displays the current HT Link speed.
2.4.1 Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking conguration options:
[Auto] Loads the optimal settings for the system.
[Manual] Allows you to individually set overclocking parameters.
[D.O.C.P.] Allows you to select a DRAM O.C. prole, and the related parameters will
be adjusted automatically.
CPU Bus Frequency [XXX]
This item appears only when you set the AI Overclock Tuner item to [Manual] or [D.O.C.P.]
and allows you to adjust the CPU and VGA frequency to enhance the system performance.
Use the <+> and <‑> keys to adjust the value. You can also key in the desired value using
the numeric keypad. The values range from 100.0MHz to 600.0MHz.
PCIE Frequency [XXX]
This item appears only when you set the AI Overclock Tuner item to [Manual] or [D.O.C.P.]
and allows you to adjust PCIE frequency to enhance the system performance. Use the <+>
and <‑> keys to adjust the value. You can also key in the desired value using the numeric
keypad. The values range from 100.0MHz to 150.0MHz.
DRAM O.C. Prole [DDR3-1600MHz]
This item appears only when you set the AI Overclock Tuner item to [D.O.C.P.] and allows
you to select a DRAM O.C. prole, which applies different settings to DRAM frequency,
DRAM timing and DRAM voltage. Conguration options: [DDR3‑1600MHz] [DDR3‑1800MHz]
[DDR3‑1866MHz] [DDR3‑2000MHz] [DDR3‑2133MHz] [DDR3‑2200MHz] [DDR3‑2400MHz]
The conguration options for the following sub‑items vary depending on the CPU/DIMMs
you install on the motherboard.
