Asus Motherboard M2V-MX User Manual

2-28 Chapter 2: BIOS Setup
Front Panel Support Type [HD Audio]
Allows you to set the front panel audio connector (AAFP) mode to
legacy AC’97 or high-denition audio depending on the audio standard
that the front panel audio module supports. Conguration options:
[AC97][HD Audio]
JMicron SATA/PATA Controller [Enabled]
Allows you to enable or disable the JMicron SATA/PATA controller.
Conguration options: [Disabled] [Enabled]
JMicron SATA Controller Mode [IDE]
Allows you to set the JMicron SATA controller mode.This item appears
only when the JMicron SATA/PATA Controller item is set to Enabled.
Conguration options: [IDE] [AHCI] [RAID]
Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Conguration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Conguration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [Normal]
Allows you to select the Parallel Port mode.
Conguration options: [Normal] [EPP] [ECP] [EPP+ECP]
Parallel Port IRQ [IRQ7]
Allows you to select the Parallel Port IRQ.
Conguration options: [IRQ5] [IRQ7]

Asus Motherboard M2V-MX Specifications

General

Form Factor	Micro ATX
Socket	AM2
Memory Slots	2
Maximum Memory	4 GB
Audio Chipset	Realtek ALC662
LAN Speed	10/100 Mbps
Onboard Video Chipset	VIA UniChrome Pro
CPU Type	Athlon 64 X2, Athlon 64, Sempron
Chipset	VIA K8M890
Memory Standard	DDR2 533
Expansion Slots	1 x PCIe x16, 2 x PCI
Storage Interface	SATA, IDE
SATA	2 x SATA 1.5Gb/s
IDE	1
USB 1.1/2.0	4 x USB 2.0
Audio	6-channel
PS/2	1 keyboard, 1 mouse
