Asus P5AD2-E - Page 77

ASUS P5AD2-EASUS P5AD2-E
ASUS P5AD2-EASUS P5AD2-E
ASUS P5AD2-E
3-213-21
3-213-21
3-21
The following items also appear when the
AI Overclocking AI Overclocking
AI Overclocking AI Overclocking
AI Overclocking item is set
to [AI NOS].
Memory Voltage [Auto]Memory Voltage [Auto]
Memory Voltage [Auto]Memory Voltage [Auto]
Memory Voltage [Auto]
Allows you to select the DDR2 reference voltage.
Configuration options: [Auto] [1.80V] [1.85V] [1.90V] [1.95V] [2.00V]
[2.05V] [2.10V] [2.20V] [Auto]
Refer to the DDR2 documentation before adjusting the memory voltage.
Setting a very high memory voltage may damage the memory module(s)!
Chipset Core Voltage [Auto]Chipset Core Voltage [Auto]
Chipset Core Voltage [Auto]Chipset Core Voltage [Auto]
Chipset Core Voltage [Auto]
Allows you to select the chipset core voltage.
Configuration options: [Auto] [1.50V] [1.55V] [1.60V] [1.65V] [1.70V]
[1.75V] [1.80V]
Setting a high chipset core voltage may damage the chipset!
CPU VCore Voltage [Auto]CPU VCore Voltage [Auto]
CPU VCore Voltage [Auto]CPU VCore Voltage [Auto]
CPU VCore Voltage [Auto]
Allows you to select the CPU VCore voltage. Configuration options: [Auto]
[1.8000V] [1.7875V] [1.7750V] [1.7625V] [1.7500V] [1.7375V]
[1.7250V] [1.7125V] [1.7000V] [1.6875V] [1.6750V] [1.6625V]
[1.6500V] [1.6375V] [1.6250V] [1.6125V] [1.6000V] [1.5875V]
[1.5750V] [1.5625V] [1.5500V] [1.5375V] [1.5250V] [1.5125V]
[1.5000V] [1.4875V] [1.4750V] [1.4625V] [1.4500V] [1.4375V]
[1.4250V] [1.4125V] [1.4000V] [1.3875V] [1.3750V] [1.3625V]
[1.3500V] [1.3375V] [1.3250V] [1.3125V] [1.3000V] [1.2875V]
Refer to the CPU documentation before setting the CPU Vcore voltage.
Setting a high Vcore voltage may damage the CPU!
PCI Express Frequency [Auto]PCI Express Frequency [Auto]
PCI Express Frequency [Auto]PCI Express Frequency [Auto]
PCI Express Frequency [Auto]
Allows you to set the PCI Express frequency. This item is set to [Auto] by
default. Configuration options: [Auto] [90]...[150]
PCI Clock Synchronization Mode [Auto]PCI Clock Synchronization Mode [Auto]
PCI Clock Synchronization Mode [Auto]PCI Clock Synchronization Mode [Auto]
PCI Clock Synchronization Mode [Auto]
Allows you to synchronize the PCI frequency with the PCI Express or CPU
frequency. Configuration options: [To CPU] [33.33MHz] [Auto]
Spread Spectrum [Auto]Spread Spectrum [Auto]
Spread Spectrum [Auto]Spread Spectrum [Auto]
Spread Spectrum [Auto]
Allows you to enable or disable the clock generator spread spectrum.
Configuration options: [Disabled] [Enabled] [Auto]
