ASUS P5GC-VM
A-3
8.
On the Power schemes section,
click
, then select any option
except
Home/Ofce Desktop or
Always On.
9.
Click
Apply
, then click
OK
.
10.
Close the Display Properties
window
.
After you adjust the power scheme,
the CPU internal frequency slightly
decreases when the CPU loading is
low
.
The screen displays and procedures may vary depending on the operating
system.
92
94
