Asus P5GD1-VM User Manual

1-281-28
1-281-28
1-28
Chapter 1: Product introductionChapter 1: Product introduction
Chapter 1: Product introductionChapter 1: Product introduction
Chapter 1: Product introduction
P5GD1-VM
®
P5GD1-VM Fan connectors
CPU_FAN
1
CHA_FAN1
GND CPU FAN PWR CPU FAN IN CPU FAN PWM
GND
Rotation
+12V
5.5.
5.5.
5.
CPU and Chassis Fan connectorsCPU and Chassis Fan connectors
CPU and Chassis Fan connectorsCPU and Chassis Fan connectors
CPU and Chassis Fan connectors
(4-pin CPU_FAN1, 3-pin CHA_FAN1)(4-pin CPU_FAN1, 3-pin CHA_FAN1)
(4-pin CPU_FAN1, 3-pin CHA_FAN1)(4-pin CPU_FAN1, 3-pin CHA_FAN1)
(4-pin CPU_FAN1, 3-pin CHA_FAN1)
The fan connectors support cooling fans of 350 mA~740 mA (8.88 W
max.) or a total of 1 A~2.22 A (26.64 W max.) at +12V. Connect the
fan cables to the fan connectors on the motherboard, making sure that
the black wire of each cable matches the ground pin of the connector.
Do not forget to connect the fan cables to the fan connectors.
Insufficient air flow inside the system may damage the motherboard
components. These are not jumpers! Do not place jumper caps on the
fan connectors!
Make sure that your Fan Power (FANPWR1) jumper setting is correct.
See page 1-22 for details.
