Fan power (3-pin FANPWR1)Fan power (3-pin FANPWR1)
Fan power (3-pin FANPWR1)Fan power (3-pin FANPWR1)
Fan power (3-pin FANPWR1)
Set this jumper to 1-2 (Default) if you are using a 4-pin CPU fan. Set
this jumper to 2-3 if you are using a 3-pin CPU fan.
We recommend the use of a 4-pin CPU fan.
P5GD2-VM
®
P5GD2-VM FAN power setting
FANPWR1
DC modePWM
(Default)
1
2
2
3
