Internal connectorsInternal connectors
Internal connectorsInternal connectors
Internal connectors
PagePage
PagePage
Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-24
2. Primary IDE connector (40-1 pin PRI_IDE1) 2-24
3. Primary RAID ATA connector (40-1 pin PRI_RAID1) 2-25
4. Secondary RAID ATA connector (40-1 pin SEC_RAID1) 2-25
5. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4) 2-26
6. CPU fan connector (4-pin CPU_FAN1) 2-27
7. Power fan connector (3-pin PWR_FAN1) 2-27
8. Chassis fan connector (3-pin CHA_FAN1) 2-27
9. Chassis fan 2 connector (3-pin CHA_FAN2) 2-27
10. Serial port connector (10-1 pin COM1) 2-28
11. USB headers (10-1 USB56, USB78) 2-28
12. ATX power connector (24-pin EATXPWR1) 2-29
13. ATX 12V power connector (4-pin ATX12V1) 2-29
14. Optical audio connector (4-pin CD) 2-30
15. GAME/MIDI connector (16-1 pin GAME1) 2-30
16. Chassis intrusion connector (4-1 pin CHASSIS1) 2-31
17. Front panel audio connector (10-1 pin AAFP) 2-31
18. System panel connectors (20-1 pin PANEL1) 2-32
- System Power LED (Green 3-pin PLED)
- Hard Disk activity (Red 2-pin IDE_LED)
- System warning speaker (Orange 4-pin SPEAKER)
- Power/Soft-off button(Yellow 2-pin PWR)
- Reset switch (Blue 2-pin RESET)
