Asus P5P41T USB3 User Manual

ASUS P5P41T/USB3 2-5
2.2.2 Menu bar
The menu bar on top of the screen has the following main items:
Main For changing the basic system conguration.
Advanced For changing the advanced system settings.
Power For changing the advanced power management (APM)
conguration.
Boot For changing the system boot conguration.
Tools For conguring options for special functions.
Exit For selecting the exit options and loading default settings.
To select an item on the menu bar, press the right or left arrow key on the keyboard until the
desired item is highlighted.
2.2.1 BIOS menu screen
Navigation keys
Submenu items
Select Screen
Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
System Time [01:36:33]
System Date [Wed 02/06/2002]
Primary IDE Master :[Not Detected]
Primary IDE Slave :[Not Detected]Primary IDE Slave :[Not Detected] :[Not Detected]
SATA 1 :[Not Detected]
SATA 2 :[Not Detected]
SATA 3 :[Not Detected]
SATA 4 :[Not Detected]
Storage Conguration
System Information
Use [ENTER], [TAB] or
[SHIFT-TAB] to select
a eld.
Use [+] or [-] to
congure system Time.
General help
Menu bar Conguration eldsMenu items
P5P41T/USB3 BIOS Setup
Main Advanced Power Boot Tools Exit
Version 0306

Asus P5P41T USB3 Specifications

General

Socket	LGA 775
Chipset	Intel P41
Form Factor	ATX
Memory Slots	4 x DIMM
Maximum Memory	8GB
North Bridge	Intel P41
South Bridge	Intel ICH7
Max. LAN Speed	10/100/1000 Mbps
USB Ports	12
USB 3.0 Ports	2 x USB 3.0
Audio	8-channel HD Audio
Expansion Slots	1 x PCIe x16 2 x PCIe x1 3 x PCI
CPU Type	Intel Core 2 Quad / Core 2 Duo / Pentium
Memory Standard	DDR3 1333/1066/800
SATA 3Gb/s	4
Audio Ports	3
Dimensions (W x L)	30.5 cm x 24.4 cm
Power Pin	24-pin ATX + 4-pin ATX12V
LAN Chipset	Realtek RTL8112L
