Asus P5W DH User Manual

5-34 Chapter 5: Software support
Creating a RAID 1 set (mirrored)
To create a RAID 1 set:
1. From the utility main menu, select 1. Create RAID Volume, then press
<Enter>. This screen appears.
2. Enter a name for the RAID 1 set, then press <Enter>.
3. When the RAID Level item is highlighted, press the up/down arrow key to
select RAID 1(Mirror), then press <Enter>.
4. When the Capacity item is highlighted, key in the RAID volume capacity that
you want, then press <Enter>. The default value indicates the maximum
allowed capacity.
5. Press <Enter> when the Create Volume item is highlighted. This warning
message appears.
Intel(R) Matrix Storage Manager Option ROM v5.0.0.1032 ICH7R wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can be used
to uniquely identify the RAID volume. This name is case sensitive and
cannot contain special characters.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [Enter]-Select
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume1
RAID1(Mirror)
Select Disks
N/A
XX.X GB
Create Volume
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
6. Press <Y> to create the RAID volume and return to main menu or <N> to go
back to Create Volume menu.

Asus P5W DH Specifications

General

Chipset	Intel 975X
Socket	LGA 775
FSB	1066/800/533 MHz
Memory Type	DDR2
Maximum Memory	8GB
Memory Standard	DDR2 800/667/533
Form Factor	ATX
Audio Chipset	ADI AD1988B
LAN Speed	10/100/1000 Mbps
Storage	4 x SATA 3Gb/s
SATA RAID	RAID 0, 1, 5, 10
PS/2	2
USB 2.0	8 x USB 2.0
IEEE 1394	2 x IEEE 1394a
Audio Ports	6 Ports
Supported CPU	Core 2 Extreme / Core 2 Duo / Pentium D / Pentium 4 / Celeron
Memory Slots	4
Audio	8-channel
LAN	Dual LAN
LAN Chipset	Marvell 88E8053
Expansion Slots	2 x PCIe x16
S/PDIF Out	Optical
