ASUS P8B-C series 5-45
Managing hot spares
You may congure one disk as a global hot spare to protect critical data on the
RAID 1/1E/10 volume(s). You may create the hot spare disk at the same time you
create the RAID 1/1E/10 volume. Refer to this section when adding a hot spare
disk on an existing volume.
If a disk on an RAID 1/1E/10 volume fails, the utility automatically rebuilds the
failed disk data on the hot spare. When the failed disk is replaced, the utility
assigns the replacement as the new hot spare.
To create a hot spare
1. Follow steps 1–3 of the section Viewing volume properties.
2. From the View Volume screen, select Manage Volume, then press <Enter>.
3. From the Manage Volume screen, select Manage Hot Spares, then press
<Enter>.
Esc = Exit Menu F1/Shift+1 = Help
Enter=Select Item Alt+N=Next Volume
LSI Corp Cong Utility v7.07.00.00 (2010.04.30)
View Volume -- SAS2008
Volume 1 of 1
Identier LSI Logical Volume 3000
Type RAID 1
Size(GB) 148
Status Optimal
Task None
Manage Volume
Slot Device Identier RAID Hot Drive Pred Size
Num Disk Spr Status Fail (GB)
0 ATA ST3160812AS E Yes No Primary No 148
1 ATA ST3160812AS E Yes No Secondary No 148
Esc = Exit Menu F1/Shift+1 = Help
Enter = Select Item
LSI Corp Cong Utility v7.07.00.00 (2010.04.30)
Manage Volume -- SAS2008
Identier LSI Logical Volume 3000
Type RAID 1
Size(GB) 148
Status Optimal
Task None
Manage Hot Spares
Consistency Check
Activate Volume
Delete Volume
Online Capacity Expansion
