6-14
Chapter 6: Driver installation
5.
Select
Y
es
to accept the terms of the
License
Agreement
and continue the
process.
6.
Read the
Readme File Information
and press
Next
to continue the
installation.
7.
After completing the installation, click
Finish
to complete the setup process.
163
