Chapter 2: BIOS information 2-21
ASM1061 Storage OPROM [Enabled]
This item appears only when you set the previous item to [Enabled] and allows you to enable
or disable the OptionRom of the ASMedia 1061 storage controller.
Conguration options: [Enabled] [Disabled]
Realtek LAN Controller [Enabled]
[Enabled] Enables the Realtek LAN controller.
[Disabled] Disables the controller.
Realtek PXE OPROM [Disabled]
This item appears only when you set the Realtek LAN Controller item to [Enabled] and
allows you to enable or disable the Rom Help of the Realtek LAN controller.
Conguration options: [Enabled] [Disabled]
Asmedia USB 3.0 Controller (Back) [Enabled]
[Enabled] Enables the Asmedia USB 3.0 controller for the USB 3.0 ports on the rear
panel.
[Disabled] Disables the controller.
PCIE Port Mode [Auto]
The PCIE Port Mode item allows you to change the port control from Asmedia USB 3.0
Controller (Front) to PCIEx1 slot and vice-versa.
[Auto]
PCIEx1_1 slot will switch to Asmedia USB 3.0 Controller (Front) unless a device is detected
in PCIEx1_1 slot.
[Asmedia USB 3.0 Controller]
Enables the Asmedia USB 3.0 Controller (Front). The PCIEx1_1 slot is disabled.
[PCIEx1 Slot]
Enables the PCIEx1_1 slot. The Asmedia USB 3.0 Controller (Front) is disabled.
Asmedia USB 3.0 Battery Charging Support [Disabled]
This item appears only when the ASMedia USB 3.0 Controller item is set to [Enabled].
[Enabled] Enables ASMedia USB 3.0 fast battery charging support for USB 3.0
devices complying with the BC 1.1 regulation.
[Disabled] Disables this function.
Serial Port Conguration
The sub-items in this menu allow you to set the serial port conguration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Conguration options: [Enabled] [Disabled]
Change Settings [IO=3F8h; IRQ=4]
Allows you to select the Serial Port base address.
Conguration options: [IO=3F8h; IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4]IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4]] [IO=3E8h; IRQ=4]IO=3E8h; IRQ=4]]
[IO=2E8h; IRQ=3]IO=2E8h; IRQ=3]]
