1-15Chapter 1: Product introduction
1.5 Expansion slots
In the future, you may need to install expansion cards. The following sub-sections describe
the slots and the expansion cards that they support.
Unplug the power cord before adding or removing expansion cards. Failure to do so may
cause you physical injury and damage motherboard components.
1.5.1 Installing an expansion card
To install an expansion card:
1. Before installing the expansion card, read the documentation that came with it and
make the necessary hardware settings for the card.
2. Remove the system unit cover (if your motherboard is already installed in a chassis).
3. Remove the bracket opposite the slot that you intend to use. Keep the screw for later
use.
 
seated on the slot.
5. Secure the card to the chassis with the screw you removed earlier.
6. Replace the system cover.
 

1. Turn on the system and change the necessary BIOS settings, if any. See Chapter 2 for
information on BIOS setup.
2. Assign an IRQ to the card.
3. Install the software drivers for the expansion card.
When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that

groups, making the system unstable and the card inoperable.
1.5.3 PCI Express 3.0/2.0 x16 slot
This motherboard has a PCI Express 3.0/2.0 x16 slot that supports PCI Express 2.0 x16


Other manuals for Asus P8H61-I LX R2.0

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H61-I LX R2.0 and is the answer not in the manual?

Asus P8H61-I LX R2.0 Specifications

General IconGeneral
Form FactorMini ITX
ChipsetIntel H61
CPU SocketLGA 1155
Memory Slots2
Memory TypeDDR3
Maximum Memory16 GB
PCIe x16 Slots1
SATA Ports4 x SATA 3Gb/s
AudioRealtek ALC887 8-Channel High Definition Audio CODEC
Video Outputs1 x DVI, 1 x HDMI
LANRealtek 8111E Gigabit LAN Controller
USB Ports8 x USB 2.0
