viii
(continued on the next page)
CPU Intel
®
Socket 1155 for Intel
®
3rd/2nd Generation processors
Supports 22nm/32nm CPU
Supports Intel
®
Turbo Boost Technology 2.0
* The Intel
®
Turbo Boost Technology 2.0 suppport depends on the
CPU types
Chipset Intel
®
H61 Express Chipset
Memory 2 x DIMM, max. 16GB, DDR3 2200 (O.C.)/2133 (O.C.)/2000
un-buffered memory
Dual-channel memory architecture
* The Max. 16GB memory capacity can be supported with DIMMs
of 8GB (or above). ASUS will update QVL once the DIMMs are
available in the market.
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows
®
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot
Graphics
Max. UMA Memory: 1748MB
Storage
Intel
®
H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors
LAN
Realtek
®
8111F PCIe Gigabit LAN controller
Audio VIA
®
- Supports Jack-Detection, Multi-Streaming and Front Panel Jack-
Retasking
USB 8 x USB 2.0/1.1 ports (4 ports at the mid-board, 4 ports at the back
panel)
ASUS unique
features
GPU Boost
ASUS Anti-Surge Protection
ASUS UEFI BIOS
ASUS Q-Fan 2
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS MyLogo 2
