ASUS P8H61-I R2.0 1-8
DDR3-1600 MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
1DIMM 2DIMM
A-DATA AM2U16BC2P1 2GB SS A-DATA
3CCD-1509A
EL1126T
- - · ·
A-DATA AD31600E001GM(O)U3K
3GB (3 x
1GB)
SS - - 8-8-8-24 1.65V-1.85V ·
A-DATA AX3U1600XB2G79-2X(XMP)
4GB (2 x
2GB)
DS - - 7-9-7-21 1.55V-1.75V
A-DATA AM2U16BC4P2 4GB DS A-DATA
3CCD-1509A
EL1126T
- - · ·
A-DATA AX3U1600GC4G9-2G(XMP)
8GB (2 x
4GB)
DS - - 9-9-9-24 1.55V-1.75V · ·
A-DATA AX3U1600XC4G79-2X(XMP)
8GB (2 x
4GB)
DS - - 7-9-7-21 1.55V-1.75V · ·
CORSAIR TR3X3G1600C8D(XMP)
3GB (3 x
1GB)
SS - - 8-8-8-24 1.65V · ·
CORSAIR CMD12GX3M6A1600C8(XMP)
12GB
(6x2GB)
DS - - 8-8-8-24 1.65V · ·
CORSAIR CMZ32GX3M4X1600C10(XMP)
32GB
(8GBx4)
DS - - 10-10-10-27 1.50V · ·
CORSAIR CMP4GX3M2A1600C8(XMP)
4GB (2 x
2GB)
DS - - 8-8-8-24 1.65V · ·
CORSAIR CMP4GX3M2A1600C9(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-24 1.65V · ·
CORSAIR CMP4GX3M2C1600C7(XMP)
4GB (2 x
2GB)
DS - - 7-8-7-20 1.65V · ·
CORSAIR CMX4GX3M2A1600C9(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-24 1.65V · ·
CORSAIR CMX4GX3M2A1600C9(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-24 1.65V · ·
CORSAIR TR3X6G1600C8 G(XMP)
6GB (3 x
2GB)
DS - - 8-8-8-24 1.65V · ·
CORSAIR TR3X6G1600C8D G(XMP)
6GB( 3 x
2GB)
DS - - 8-8-8-24 1.65V · ·
CORSAIR TR3X6G1600C9 G(XMP)
6GB (3 x
2GB)
DS - - 9-9-9-24 1.65V · ·
CORSAIR CMP8GX3M2A1600C9(XMP)
8GB (2 x
4GB)
DS - - 9-9-9-24 1.65V · ·
CORSAIR CMZ8GX3M2A1600C7R(XMP)
8GB (2 x
4GB)
DS - - 7-8-7-20 1.50V · ·
CORSAIR CMX8GX3M4A1600C9(XMP)
8GB(4 x
2GB)
DS - - 9-9-9-24 1.65V · ·
Crucial BL25664BN1608.16FF(XMP)
6GB(3 x
2GB)
DS - - - - · ·
G.SKILL F3-12800CL9D-2GBNQ(XMP)
2GB (2 x
1GB)
SS - - 9-9-9-24 1.5V · ·
G.SKILL F3-12800CL7D-4GBRH(XMP)
4GB (2 x
2GB)
SS - - 7-7-7-24 1.6V · ·
G.SKILL F3-12800CL7D-4GBECO(XMP)
4GB (2 x
2GB)
DS - - 7-7-8-24 XMP 1.35V · ·
G.SKILL F3-12800CL7D-4GBRM(XMP)
4GB (2 x
2GB)
DS - - 7-8-7-24 1.6V · ·
G.SKILL F3-12800CL8D-4GBRM(XMP)
4GB (2 x
2GB)
DS - - 8-8-8-24 1.60V · ·
G.SKILL F3-12800CL9D-4GBECO(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-24 XMP 1.35V · ·
G.SKILL F3-12800CL9D-4GBRL(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-24 1.5V · ·
G.SKILL F3-12800CL9T-6GBNQ(XMP)
6GB (3 x
2GB)
DS - - 9-9-9-24 1.5V~1.6V · ·
G.SKILL F3-12800CL7D-8GBRH(XMP)
8GB (2 x
4GB)
DS - - 7-8-7-24 1.6V · ·
G.SKILL F3-12800CL8D-8GBECO(XMP)
8GB (2 x
4GB)
DS - - 8-8-8-24 XMP 1.35V · ·
G.SKILL F3-12800CL9D-8GBRL(XMP)
8GB (2 x
4GB)
DS - - 9-9-9-24 1.5V · ·
GEIL GET316GB1600C9QC(XMP)
16GB ( 4x
4GB )
DS - - 9-9-9-28 1.6V · ·
GEIL GV34GB1600C8DC(XMP) 2GB DS - - 8-8-8-28 1.6V · ·
HYNIX HMT351U6CFR8C-PB 4GB DS HYNIX
H5TQ2G83CFR
PBC
- - · ·
KINGMAX FLGD45F-B8MF7 MAEH(XMP) 1GB SS - - 7 -
KINGMAX FLGE85F-B8KJ9A FEIS(XMP) 2GB DS - - - - · ·
KINGMAX FLGE85F-B8MF7 MEEH(XMP) 2GB DS - - 7 - · ·
(continued on the next page)
