Page #20 background imageLoading...
Page #20 background image
ASUS P8H61-I R2.0 1-10
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket
support
(Optional)
1
DIMM
2
DIMMs
A-Data AD31333001GOU 1GB SS A-Data AD30908C8D-151C
E0906
- -
A-Data AD31333G001GOU 3GB(3 x 1GB) SS - - 8-8-8-24 1.65-1.85V
A-Data AD31333002GOU 2GB DS A-Data AD30908C8D-151C
E0903
- -
A-Data AD31333G002GMU 2GB DS - - 8-8-8-24 1.65-1.85V
Apacer 78.A1GC6.9L1 2GB DS APACER AM5D5808DEWSBG - -
Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808FEQSBG 9 -
CORSAIR CM3X1024-1333C9DHX 1GB SS - - 9-9-9-24 1.60V
CORSAIR CM3X1024-1333C9 1GB SS - - 9-9-9-24 1.60V
CORSAIR TR3X3G1333C9 G 3GB(3 x 1GB) SS - - 9-9-9-24 1.50V
CORSAIR TR3X3G1333C9 G 3GB(3 x 1GB) SS - - 9-9-9-24 1.50V
CORSAIR CM3X1024-1333C9DHX 1GB DS Corsair - - -
CORSAIR CMD24GX3M6A1333C9(XMP) 24GB(6x4GB) DS - - 9-9-9-24 1.60V
CORSAIR CM3X2048-1333C9DHX 2GB DS - - - -
CORSAIR CMX8GX3M4A1333C9 8GB(4 x 2GB) DS - - 9-9-9-24 1.50V
Crucial CT12864BA1339.8FF 1GB SS Micron 9FF22D9KPT 9 -
Crucial CT25664BA1339.16FF 2GB DS Micron 9KF27D9KPT 9 -
Crucial BL25664BN1337.16FF (XMP) 6GB(3 x 2GB) DS - - 7-7-7-24 1.65V
ELPIDA EBJ10UE8EDF0-DJ-F 1GB SS ELPIDA J1108EDSE-DJ-F - 1.35V(low
voltage)
ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F - 1.35V(low
voltage)
G.SKILL F3-10600CL8D-2GBHK(XMP) 1GB SS G.SKILL - - -
G.SKILL F3-10666CL7T-3GBPK(XMP) 3GB(3 x 1GB) SS - - 7-7-7-18 1.5~1.6V
G.SKILL F3-10666CL9T-3GBNQ 3GB(3 x 1GB) SS - - 9-9-9-24 1.5~1.6V
G.SKILL F3-10600CL9D-2GBNQ 1GB DS G.SKILL - - -
G.SKILL F3-10600CL8D-4GBHK(XMP) 4GB(2 x 2GB) DS - - 8-8-8-21 1.5-1.6V
G.SKILL F3-10666CL8D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 8-8-8-
8-24
XMP 1.35V
G.SKILL F3-10666CL7T-6GBPK(XMP) 6GB(3 x 2GB) DS - - 7-7-7-18 1.5~1.6V
G.SKILL F3-10666CL7D-8GBRH(XMP) 8GB(2 x 4GB) DS - - 7-7-7-21 1.5V
G.SKILL F3-10666CL9D-8GBRL 8GB(2 x 4GB) DS - - 9-9-9-24 1.5V
GEIL GET316GB1333C9QC 16GB ( 4x
4GB )
DS - - 9-9-9-24 1.5V
GEIL GV32GB1333C9DC 2GB(2 x 1GB) DS - - 9-9-9-24 1.5V
GEIL GV34GB1333C7DC 2GB DS - - 7-7-7-24 1.5V
GEIL GG34GB1333C9DC 4GB(2 x 2GB) DS GEIL GL1L128M88BA12N 9-9-9-24 1.3V(low
voltage)
GEIL GV34GB1333C9DC 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V
Hynix HMT112U6TFR8A-H9 1GB SS HYNIX H5TC1G83TFRH9A - 1.35V(low
voltage)
HYNIX HMT325U6BFR8C-H9 2GB SS HYNIX H5TQ2G83BFRH9C - -
Hynix HMT125U6TFR8A-H9 2GB DS HYNIX H5TC1G83TFRH9A - 1.35V(low
voltage)
HYNIX HMT351U6BFR8C-H9 4GB DS HYNIX H5TQ2G83BFRH9C - -
KINGMAX FLFD45F-B8KL9 NAES 1GB SS KINGMAX KKB8FNWBFGNX-27A - -
KINGMAX FLFE85F-C8KF9 CAES 2GB SS KINGMAX KFC8FMFXF-DXX-15A - -
KINGMAX FLFE85F-C8KM9 NAES 2GB SS KINGMAX KFC8FNMXF-
BXX-15A
- -
KINGMAX FLFE85F-B8KL9 NEES 2GB DS KINGMAX KKB8FNWBFGNX-26A - -
KINGMAX FLFF65F-C8KM9 NEES 4GB DS KINGMAX KFC8FNMXF-
BXX-15A
- -
Kingston KVR1333D3N9/1G 1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V
KINGSTON KVR1333D3N9/2G 2GB SS HYNIX H5TQ2G83AFRH9C 9 -
KINGSTON KVR1333D3N9/2G(low prole) 2GB DS ELPIDA J1108BDBG-DJ-F 9 1.5V
Kingston KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V
Kingston KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V
DDR3-1333 MHz capability
(continued on the next page)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H61-I R2.0 and is the answer not in the manual?

Asus P8H61-I R2.0 Specifications

General IconGeneral
ECCNo
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600, 1800, 2000, 2200 MHz
System bus rate5 GT/s
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors1
Number of SATA II connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Headphone outputs3
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chipVIA VT1708S
Cooling typePassive
Component forPC
Power source typeATX
Motherboard chipsetIntel® H61
PC health monitoringCPU, FAN, Temperature
Audio output channels7.1 channels
Motherboard form factormini ITX
Supported storage drive interfacesSATA, SATA II
Graphics cardHD Graphics
Maximum resolution2048 x 1536 pixels
Maximum graphics card memory1748 MB
Parallel processing technology supportNot supported
PCI Express slots version2.0, 3.0
PCI Express configurations1x16
Special features2 x Thunderbolt
Cables includedSATA
LAN controllerRealtek RTL8111F
Networking featuresGigabit LAN
Ethernet interface typeFast Ethernet, Gigabit Ethernet
BIOS typeEFI AMI
ACPI version2.0a
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Width171 mm
