P8H61-M LE Series specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
Second Generation Core™ i7 / Core™
i5 / Core™ i3 processors
Supports 32nm CPU
Supports Intel
®
Turbo Boost technology 2.0
* The Intel
®
Turbo Boost technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H61 Express Chipset
Memory 2 x DIMM, max. 16GB*, DDR3 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* The maximum 16GB memory capacity can be supported with
8GB or above DIMMs. ASUS will update the memory QVL once
the DIMMs are available in the market.
** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows
®
32-bit operating system.
Graphics Dual independent displays support: DVI and D-Sub
Supports Single-link DVI with max. resolution up to 1920x1200
@60Hz
Supports D-Sub with max. resolution up to 2048x1536 @75Hz
Supports Microsoft
®
DirectX 10.1
Intel
®
Quick Sync Video technology support
Expansion slots 1 x PCI Express 2.0 x16 slot
2 x PCI Express 2.0 x1 slots
1 x PCI slot
Storage
Intel
®
H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors
LAN
Realtek
®
8111E Gigabit LAN controller
Audio Realtek
®
ALC887 8-channel* High Denition Audio CODEC
* Use a chassis with HD audio module in the front panel to
support an 8-channel audio output.
USB P8H61-M LE:
Intel
®
H61 Express Chipset:
- 10 x USB 2.0/1.1 ports (4 ports at the mid-board, 6 ports
at the back panel)
P8H61-M LE/USB3:
Intel
®
H61 Express Chipset:
- 8 x USB 2.0/1.1 ports (4 ports at the mid-board, 4 ports
at the back panel)
Asmedia USB3.0 controller:
- 2 x USB 3.0/2.0 ports (blue, at the back panel)
