P8H61-M LK R2.0 specications summary
Specications are subject to change without notice.
Rear panel ports
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x D-Sub port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
3 x Audio jacks
Internal connectors/
jumpers
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1
ports
4 x SATA 3.0 Gb/s connectors
1 x 4-pin CPU fan connector
1 x 4-pin chassis fan connector
1 x Front panel audio connector
1 x System panel connector
1 x Speaker header
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, EFI BIOS, PnP, DMI v2.0, WfM 2.0, ACPI
v2.0a, SM BIOS v2.7, SLP 3.0, EUP-ready
Manageability
WOL, PXE, PME Wake Up
Accessories
2 x Serial ATA 3.0Gb/s cables
1 x I/O shield
1 x User Manual
1 x Support DVD
Support DVD
Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
Form factor
uATX form factor: 8.9 in x 6.8 in (22.6 cm x 17.3 cm)

Asus P8H61-M LK R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Supported memory module capacities	2GB, 4GB, 8GB
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1024 MB
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express slots quantity	3
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	173 mm
Width	226 mm
