Asus P8H61-M LX PLUS Quick Start Guide

ASUS P8H61-M LX Series 11
Step 7
Installer les connecteurs d’alimentation ATX
Installieren des ATX-Stromanschlusses
Installare i connettori di alimentazione ATX
Instalar conectores de alimentación ATX
Установка ATX разъема
Instale os conectores de alimentação ATX
Instalacja złączy zasilacza ATX
Instalace konektorů napájení ATX
Csatlakoztassa az ATX tápcsatlakozókat
Инсталирайте ATX конекторите за захранване
Instalaţi pinii conectori ATX
Instalirajte ATX električne priključke
ATX güç konnektörlerini takın
ATX электр қуат қосқыштарын орнатыңыз
21

Asus P8H61-M LX PLUS Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DIMM
Memory Type	DDR3
Maximum Memory	16GB
PCI Express x16	1
PCI Express x1	2
SATA Ports	4 x SATA 3Gb/s
Audio Chipset	Realtek ALC887
Audio	Realtek ALC887
LAN	Realtek 8111E
Video Outputs	VGA
Power Connector	24-pin ATX
USB Ports	8 (4 on back panel, 4 via headers)
