4 ASUS P8H61-M LX Series

P8H61-M LX PLUS

PCIEX16

PCIEX1_1

PCIEX1_2

PCIEX1_3

F_PANEL

SPEAKER

AAFP

ATX12V

EATXPWR

CPU_FAN

CHA_FAN

Lithium Cell

CMOS Power

Super

I/O

ALC

887

RTL

8111E

EPU

32Mb

BIOS

SB_PWR

SPDIF_OUT

LGA1155

Intel

H61

DDR3 DIMM_A1 (64bit, 240-pin module)

DDR3 DIMM_B1 (64bit, 240-pin module)

SATA3G_1

SATA3G_3

SATA3G_2

SATA3G_4

AUDIO

KBMS

LAN1_USB12

USB34

USB56 USB78 USB910

VGA

LPT

COM

Step 1

Step 7

Step 3

Step 5

Step 4

Step 7

Step 2

Step 6

Other manuals for Asus P8H61-M LX PLUS

User Manual66 pages

Questions and Answers:

Need help?

Do you have a question about the Asus P8H61-M LX PLUS and is the answer not in the manual?

Asus P8H61-M LX PLUS Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2 x DIMM
Memory Type	DDR3
Maximum Memory	16GB
PCI Express x16	1
PCI Express x1	2
SATA Ports	4 x SATA 3Gb/s
Audio Chipset	Realtek ALC887
Audio	Realtek ALC887
LAN	Realtek 8111E
Video Outputs	VGA
Power Connector	24-pin ATX
USB Ports	8 (4 on back panel, 4 via headers)
