ASUS P8H61-M LX Series 5
Step 1
Installer le CPU
Installieren der CPU
Installare la CPU
Instalar la CPU
Установка процессора
Instale a CPU
Instalacja procesora
Instalace procesoru
Helyezze be a CPU-t
Инсталирайте процесора
Instalaţi CPU-ul
Instalirajte CPU
CPU’yu takın
CPU орнатыңыз
A
B
1 2 3
C
B
A
4 5 6

Other manuals for Asus P8H61-M LX PLUS

Preview: User Manual
User Manual66 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H61-M LX PLUS and is the answer not in the manual?

Asus P8H61-M LX PLUS Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel H61
CPU SocketLGA 1155
Memory Slots2 x DIMM
Memory TypeDDR3
Maximum Memory16GB
PCI Express x161
PCI Express x12
SATA Ports4 x SATA 3Gb/s
Audio ChipsetRealtek ALC887
AudioRealtek ALC887
LANRealtek 8111E
Video OutputsVGA
Power Connector24-pin ATX
USB Ports8 (4 on back panel, 4 via headers)
