P8H61-M LX specications summary
ASUS Exclusive
Overclocking
ASUS C.P.R. (CPU Parameter Recall)
Rear panel ports 1 x PS/2 keyboard (Purple)
1 x PS/2 Mouse (Green)
1 x D-Sub port
1 x LAN (RJ-45) port
1 x COM port
1 x LPT port
4 x USB 2.0/1.1 ports
3 x Audio jacks support 8-channel
Internal connectors/
switches/ buttons
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1
ports
4 x SATA 3.0 Gb/s connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x speaker connector
1 x System panel connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
BIOS features 32 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM 2.0,
ACPI v2.0a, SM BIOS v2.6, Multi-language BIOS
Accessories 2 x Serial ATA 3.0Gb/s cables
1 x I/O shield
1 x User Manual
1 x Support DVD
Support DVD Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
Form factor
MicroATX form factor: 9.6 in x 7.6 in (24.4 cm x 19.3 cm)
* Specications are subject to change without notice.

Asus P8H61-M LX REV 3.0 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2 x DIMM
Memory Type	DDR3
Maximum Memory	16 GB
PCI Express x16	1
PCI Express x1	2
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E, 1 x Gigabit LAN
Video Outputs	1 x D-Sub
Power Connector	24-pin ATX
USB Ports	8 x USB 2.0
