Asus P8H61-MX R2.0 User Manual

x
P8H61-MX Series specications summary
ASUS unique features ASUS MyLogo 2™
ASUS Anti-Surge Protection
ASUS UEFI BIOS
ASUS EZ Flash 2
ASUS FanXpert
ASUS AI Charger (P8H61-MX R2.0 only)
ASUS AI Charger+ (P8H61-MX USB3 only)
ASUS Q-Fan 2
ASUS CrashFree BIOS 3
ASUS GPU Boost
Rear panel ports 1 x PS/2 keyboard / mouse combo port
1 x DVI port
1 x D-Sub port
1 x LAN (RJ-45) port
P8H61-MX R2.0:
- 6 x USB 2.0/1.1 ports
P8H61-MX USB3:
- 4 x USB 2.0/1.1 ports
- 2 x USB 3.0 ports
3 x Audio jacks
Internal connectors/
switches/ buttons
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1
ports
4 x SATA 3.0 Gb/s connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x Front panel audio connector
1 x Speaker header
1 x Front panel header
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
BIOS features 64 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM 2.0, ASUS
EZ Flash 2, ASUS CrashFree BIOS 3, SMBIOS v2.6, ACPI v2.0a,
Multi-language BIOS
Manageability
WOL, PME Wake Up, PXE
Accessories 2 x Serial ATA 3.0Gb/s cables
1 x I/O shield
1 x User Manual
1 x Support DVD
Support DVD Drivers
ASUS Utilities
ASUS Update
Anti-virus software (OEM version)
Form factor
uATX form factor: 9.6 in x 7.2 in (24.4 cm x 18.3 cm)
* Specications are subject to change without notice.

Asus P8H61-MX R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 2000, 2133, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Headphone outputs	3
USB 2.0 ports quantity	6
Audio chip	VIA VT1708S
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA, SATA II
Graphics card	HD Graphics
Maximum resolution	2048 x 1536 pixels
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Special features	2 x Thunderbolt
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	183 mm
Width	244 mm
